CAMS 557CHN 07-17TC

Beskrivning av CAMS 557CHN 07-17TC

557 Series Grind Cam Kit

Designed for Tri-Glides and other heavy bikes needing good bottom and mid-range performance

Camshaft's stock base circle permits the use of stock pushrods

Short duration produces lots of usable torque

Bolt-in design

Kit includes camshafts, gearcover gasket, bearings, retaining ring, o-ring, thread lock and instructions

Not recommended with compression ratio of 10.0:1 or higher.

Type	Chain
Brand	S&S CYCLE
Grind	557 Series
Units	Kit
Application	Exhaust| Intake
Intake lift	0,557"
Intake open	6°
Exhaust lift	0,557"
Exhaust open	39°
Product name	Camshaft Kit
Riding style	Street
Exhaust close	12°
Research value	Finalized
Intake duration	212°
Exhaust duration	231°
Intake lift at tdc	0,113"
Vendor part number	330-0105
Exhaust lift at tdc	0,146"
Intake lift imperial	0.557"
Intake open imperial	6°
Exhaust lift imperial	0.557"
Exhaust open imperial	39°
Exhaust close imperial	12°
Intake lobe centerline	100°
Exhaust lobe centerline	103°
Intake duration imperial	212°
Exhaust duration imperial	231°
Intake lift at tdc imperial	0.113"
Exhaust lift at tdc imperial	0.146"
Intake lobe centerline imperial	100°
Exhaust lobe centerline imperial	103°
