CAM 475G W/PLT OC/CHR M8

Cam Chest Kit for M8

All parts in each kit are matched to ensure superior quality, fit, finish and performance

Oil pump and cam plate are precision-machined from billet aluminum with a blue anodized finish

Passage plugs removable for servicing

Independent scavenge sections for the flywheel cavity and cam chest

Debris screens in both scavenge pickups

Increased oil flow capacity on both the feed and scavenge sides

Adjustable Pressure Relief Valve is adjustable with unit installed in engine

Magnet in cam chest to help to stop debris from entering oil pump

S&S Quickee Pushrods with finished pushrod tubes

S&S premium tappets

Billet aluminum tappet cuffs have a hard-anodized black coating and are stronger than stock to eliminate distortion

Improved tappet stability in high-lift and high-rpm situations

Provides improved cam timing accuracy and eliminates the stock cam chain tensioner

Includes outer drive gears, all gaskets, bearings, and hardware required for a complete installation

Made in the USA

475 is a bolt-in 100 horsepower cam. Kit Includes: • Oil Pump Screw Kit • 475G Camshaft • Cam Drive Gear Kit • 31 Tooth Pinion Gear • Camshaft Installation Kit • Quickee Pushrod Kit with Chrome Covers • Tappet Cuffs Lifter Guide • 3" S&S® Blue and White Logo Decal • Cam Plate Support Assembly • Oil Cooled Oil Pump Assembly • Hydraulic Precision Tappet Set • 1 oz Torco® Engine Assembly Lube
